Authentication Configuration Methods for External Systems

Alation Cloud Service Applies to Alation Cloud Service instances of Alation

Customer Managed Applies to customer-managed instances of Alation

Applies from version 2022.3

For the data sources that support authentication with external systems, Server Admins can create the required authentication configurations on the Admin Settings > Authentication page.

Create a New Configuration

We recommend performing this configuration after completing the preliminary configuration steps in the relevant external systems. Configurations can be created for the AWS IAM, OAuth, Azure Keyvault, and AWS Secrets Manager authentication methods. If you’re configuring access to AWS Secrets Manager, see Configure Secrets for OCF Connector Settings for detailed help with each of these configurations. If you are configuring SSO authentication in Compose for a data source, refer to the specific data source documentation to learn which external configuration method to use. For a general explanation of the required and optional fields for each of the authentication methods, see the sections below:

To create a new configuration:

  1. Log in to your Alation instance as a Server Admin.

  2. Click the Admin Settings gear icon on top right to open the Admin Settings page.

  3. Click Authentication to open the Authentication tab. Locate the section Authentication Configuration Methods for External Systems.

  4. If you’re on a customer-managed (on-prem) instance of Alation or an Alation Cloud Service instance that hasn’t been migrated to the cloud-native architecture, skip to the next step.

    If you’re on the Alation Cloud Service cloud-native architecture, click the drop-down menu next to See configurations for to choose the location of the configuration:

    • Choose Alation Cloud Service to see authentication configurations that have been created for Alation Cloud Service itself.

    • Choose the name of an Alation Agent to see configurations for an Agent. An Agent name will only be listed if you’ve installed the Authentication Service Add-on on that Agent.

    Note

    If any configurations already exist, you’ll see them listed in the table under Authentication Configuration Methods for External Systems. If they were created on the Alation server backend in a previous release, the columns Created At, Created By, Updated By, and Updated At will contain the value Not Set. These fields only capture the changes made in the user interface. For new configurations created in the user interface, these columns will be populated. For the configurations created on the server backend, the Updated At column will be populated if edits are made to the configuration in the user interface.

  5. Click the Add Configuration button to the right of the section title to expand the list of options and then click the name of the appropriate plug-in. If you’re creating a configuration for an Alation Agent, the only option is AWS Secrets Manager. The corresponding settings page will open in a new browser tab.

    ../../_images/Admin_Auth_AddConfiguration.png

  6. On the configuration method editor page, fill in the appropriate information.

    Note

    When creating a new configuration, you can switch between the plug-in types using the Method list. After saving a configuration, the Method field becomes read-only.

  7. After populating the fields, click Save to save the configuration. If you get an error while saving, see the Troubleshooting section for help.

  8. Refresh the Authentication page. The new configuration will be displayed in the table.

  9. Continue the configuration in the data source settings. You will need to associate your specific data source with the configuration you created under Authentication Configuration Methods for External Systems. The steps to configure a data source depend on the database type. Follow the relevant connector documentation to complete this configuration.

Troubleshooting

Something Went Wrong

In some rare cases, you may see the Something went wrong error on the Authentication page or in the configuration editor when saving a configuration.

This error may indicate that AuthService has been stopped. To resolve this issue, check the status of AuthService and restart it. For information about starting AuthService, see, for example, Enable AuthService.

../../_images/Admin_Auth_SomethingWentWrong.png

Changes Unsaved

The Changes unsaved error message may appear after clicking the Save button on the configuration editor page.

../../_images/Admin_Auth_ChangesUnsaved.png

This error means that some fields do not pass validation. Make sure you enter the values in the required format.

AWS IAM

Use this section to review the information you will need to provide in the Alation user interface when configuring authentication for your data source with AWS IAM.

../../_images/Admin_Auth_AWS_IAM.png

Field

Required?

Description

Config Name

Yes

A name for the configuration that is being created. The Config Name value will be used to identify and manage the corresponding configuration on the Alation server.

  • Config Name cannot be edited after saving the configuration.

  • Config Name should be unique.

  • Do not use any of the reserved config names. See Reserved Config Names below.

  • Config Name should not be present in the excluded_configs_in_auth_ui alation_conf parameter. See Blocking Config Names below.

STS Duration

Yes

The lifetime of the temporary credentials generated by the AWS STS service (in seconds). You can provide a value from 900 seconds (15 minutes) up to the maximum of 43200 seconds (12 hours).

Region

Yes

The AWS region of the AWS account used for authentication. This field is a list containing all supported AWS regions.

Cred Type

No

Type of authentication to use when the AWS AssumeRole API operation of the authentication flow assumes a role.

Supported values:

  • instance_profile — Use instance_profile when configuring extraction from AWS data sources. This choice relies on permissions associated with the EC2 instance role.

  • credentials — Use credentials when configuring authentication for Compose. This choice relies on the IAM user credentials.

SAML authenticate request XML

No

The request XML to be used for SAML authentication.

Multi role flow

No

Indicates if multiple roles may be returned in the SAML response. Selected by default.

Encode Relay State

No

Indicates if the relay state needs to be encoded.

Redirect URL

No

The redirect URL for the identity provider. Mandatory if the configuration is used for SAML authentication.

This should be a valid URL.

Entity Id

No

A string value that represents the Entity ID used in the <Issuer> element of the <AuthNRequest>. This value is usually used when the same Alation instance is authenticated against different IdP endpoints.

Uses the default of https://www.alation.com if this field is not populated.

This value should be a valid URL.

OAuth

Use this section to review the information you will need to provide in the Alation user interface when configuring authentication for your data source with Azure AD using the OAuth protocol.

../../_images/Admin_Auth_OAuth.png

Field

Required?

Description

Config Name

Yes

A name for the configuration that is being created. The Config Name value will be used to identify and manage the corresponding configuration on the Alation server.

  • Config Name cannot be edited after saving the configuration.

  • Config Name should be unique.

  • Do not use any of the reserved config names. See Reserved Config Names below.

  • Config Name should not be present in the excluded_configs_in_auth_ui alation_conf parameter. See Blocking Config Names below.

Client Id

Yes

The client ID of the Azure AD application.

Client Secret

Yes

The client secret of the Azure AD application.

Scope

Yes

The scope of the request. Some examples can be openid, email, profile, and offline_access.

Subject

No

This field indicates which claim in the token should be used as username, for example: unique_id or name.

Token Buffer time

No

Buffer time to check the token validity before it expires so that the token can be refreshed before expiration.

Set in minutes.

Default: five minutes (5).

Allowed values: one through ten minutes (1 - 10).

Grant Type

No

Grant types:

  • auth_code — Default. The default value is used if the field is not populated. Use this grant type if you are creating a configuration for a user-initiated authentication flow, such as authentication to a data source from Compose.

  • credentials_flow — Use this grant type if you are creating a configuration for authentication on the database for extraction of metadata.

PKCE Verifier

No

Enable or disable Proof Key for Code Exchange in your authentication flow.

Default: enabled.

Authorize Endpoint URL

Yes

The Authorize Endpoint URL for the identity provider. This should be a valid URL.

Redirect URL

Yes

Redirect URL for the identity provider. This should be a valid URL.

Token Endpoint URL

Yes

Token URL for the identity provider. This should be a valid URL.

User Info Endpoint URL

Yes

User Info Endpoint URL for the identity provider. This should be a valid URL.

Azure Keyvault

Use this section to review the information you will need to provide in the Alation user interface when configuring authentication for extraction from your data source with Azure AD and Azure Keyvault.

../../_images/Admin_Auth_Keyvault.png

Field

Required?

Description

Config Name

Yes

A name for the configuration that is being created. The Config Name value will be used to identify and manage the corresponding configuration on the Alation server.

  • Config Name cannot be edited after saving the configuration.

  • Config Name should be unique.

  • Do not use any of the reserved config names. See Reserved Config Names below.

  • Config Name should not be present in the excluded_configs_in_auth_ui alation_conf parameter. See Blocking Config Names below.

Client Id

Yes

The client ID value of the Azure AD application.

Client Secret

Yes

The client secret value of the Azure AD application.

Tenant Id

Yes

The tenant ID value of the Azure AD application.

Vault URL

Yes

The URL to access the Azure key vault. This should be a valid URL.

AWS Secrets Manager

Applies from 2023.1.5

Use this section to review the information you will need to provide in the Alation user interface when configuring integration with AWS Secrets Manager for authentication to your data source.

../../_images/Admin_Auth_AWS_SM.png

Field

Required?

Description

Config Name

Yes

A name for the configuration that is being created. The Config Name value will be used to identify and manage the corresponding configuration on the Alation server.

  • Config Name cannot be edited after saving the configuration.

  • Config Name should be unique.

  • Do not use any of the reserved config names. See Reserved Config Names below.

  • Config Name should not be present in the excluded_configs_in_auth_ui alation_conf parameter. See Blocking Config Names below.

Region

Yes

The AWS region of the Secrets Manager service. This field is a list containing all supported AWS regions.

Authentication Type

Yes

Type of authentication to use. Supported values:

  • IAM User (iam_user on versions before 2024.1.1): User credentials must be provided and the user should have read access to AWS Secrets Manager.

  • IAM Role (iam_role on versions before 2024.1.1): - The role attached to Alation’s EC2 instance will assume the given role that has access to AWS Secrets Manager. - The given role will be assumed on behalf of a user if the credentials of the user AWS Access Key and AWS Secret Key are provided.

  • IAM Instance Profile (on Alation Cloud Service version 2024.1.4 or later, if an Alation Agent has the Auth Service plugin installed): A role has read access to AWS Secrets Manager and is attached to the Alation Agent EC2 machine.

  • IAM User Profile (on Alation Cloud Service version 2024.1.5 or later, if an Alation Agent has the Auth Service plugin installed): A user has read access to AWS Secrets Manager and their keys are stored on the Alation Agent machine.

Profile Name

Yes, if authentication type is IAM User Profile.

Name of the profile defined on the Alation Agent machine. See Access Secrets Manager from Alation Agent Using an IAM User’s Credentials for help setting up this type of integration.

AWS Access Key

Yes, if authentication type is IAM User.

AWS Access Key

AWS Secret Key

Yes, if authentication type is IAM User.

AWS Secret Key

Role ARN

Yes, if authentication type is IAM Role.

Amazon Resource Name (ARN) of the role to be assumed.5cm

External ID

Yes, if authentication type is IAM Role.

External ID passed during the Assume Role operation. The external ID is needed to avoid the confused deputy problem*.

STS Duration

Yes, if authentication type is IAM Role.

The lifetime of the temporary credentials generated by the AWS STS service (in seconds). You can provide a value from 900 seconds (15 minutes) up to the maximum of 43200 seconds (12 hours).

* See this AWS documentation for more information on the confused deputy problem.

Reserved Config Names

On the Alation server, there are Config Names that are reserved and cannot be used when creating new configurations. These values are stored in these two alation_conf parameters:

  • alation.authentication.oidc.authservice_plugin_config = oauth_login_config

  • alation.authentication.oidc.authservice_plugin_test_config = oauth_login_test_config

Blocking Config Names

It is possible to block the creation of new configurations with specific names in the user interface or to hide existing configurations with specific names from the user interface. To prevent a configuration with a specific name from being created or visible, use the parameter alation.authentication.excluded_configs_in_auth_ui in alation_conf. The configurations with the names added to the list of values of this parameter, will not be visible in the Authentication Configuration Methods for External Systems table. Also, users will not be able to create a new configuration with any of the listed names.

Note

Alation Cloud Service customers can request server configuration changes through Alation Support.

On how to use alation_conf, see Using alation_conf. The Django server restart is required if the value of alation.authentication.excluded_configs_in_auth_ui is changed.

alation_supervisor restart web:*

View or Edit a Configuration

You can view and edit the settings of existing configurations. To view or edit a configuration:

  1. Log in to your Alation instance as a Server Admin.

  2. Click the Admin Settings gear icon on top right to open the Admin Settings page.

  3. Click Authentication to open the Authentication tab. Locate the section Authentication Configuration Methods for External Systems.

  4. If you’re on a customer-managed (on-prem) instance of Alation or an Alation Cloud Service instance that hasn’t been migrated to the cloud-native architecture, skip to the next step.

    If you’re on the Alation Cloud Service cloud-native architecture, click the drop-down menu next to See configurations for to choose the location of the configuration:

    • Choose Alation Cloud Service to see authentication configurations that have been created for Alation Cloud Service itself.

    • Choose the name of an Alation Agent to see configurations for an Agent. An Agent name will only be listed if you’ve installed the Authentication Service Add-on on that Agent.

  5. In the Authentication Configuration Methods for External Systems table, click View/Edit for the configuration you want to view or edit. The configuration editor page will open in a new browser tab.

  6. Edit the values as necessary.

    Note

    The fields Methods and Config Name cannot be changed.

  7. Click Save.

Delete a Configuration

It is possible to delete existing configurations. Currently, Alation does not validate if the configuration that is being deleted is in use in the application. Before deleting a configuration, make sure it is not associated with any data sources by checking the settings of your data sources. To delete:

  1. Log in to your Alation instance as a Server Admin.

  2. Click the Admin Settings gear icon on top right to open the Admin Settings page.

  3. Click Authentication to open the Authentication tab. Locate the section Authentication Configuration Methods for External Systems.

  4. If you’re on a customer-managed (on-prem) instance of Alation or an Alation Cloud Service instance that hasn’t been migrated to the cloud-native architecture, skip to the next step.

    If you’re on the Alation Cloud Service cloud-native architecture, click the drop-down menu next to See configurations for to choose the location of the configuration:

    • Choose Alation Cloud Service to see authentication configurations that have been created for Alation Cloud Service itself.

    • Choose the name of an Alation Agent to see configurations for an Agent. An Agent name will only be listed if you’ve installed the Authentication Service Add-on on that Agent.

  5. In the Authentication Configuration Methods for External Systems table, click Delete for the configuration you want to delete.

  6. In the delete confirmation dialog that pops up, click Delete to confirm your action. The configuration will be deleted.
